Baking Pan Washers

Our washers are 100% tailor-made to your specifications, and you can get a better experience by adding some options. For example, if you want to reduce further labor costs, we can achieve a one-person operation by adding conveyor belts and collecting bins.

Baking Pan Washer

The baking pan washer can remove residual oil, starch, sugar, baking residue, and other contaminants on the pan surface, ensuring the food in contact with it is hygienic. In addition to the essential cleaning function, it can disinfect and dry pans, achieving high hygiene standards while reducing the time required for re-use.

Since manual cleaning can’t ensure each pan gets the same cleaning effect, and the washing capacity is small, more and more companies are beginning to use washers to replace manual. Besides, it protects the operator from hot water or alkaline detergents.

The pan washer is mainly used in the bakery and confectionery industry, which can improve cleaning efficiency and protect sheet pans from bacteria, microorganisms, and foreign chemicals. It is compatible with many types and sizes of pans, such as 18 x 26 inches aluminum sheet pans, carbon steel bread pans with Teflon coating, stainless steel baking sheets, etc.

bread pan washer
+
Happy Clients
+
Hours Saved
+
Countries

Key Advantages

Excellent cleaning

It can effectively remove dust, oil, sugar, and other contaminants from pans, thus avoiding cross-contamination.

energy-saving

It utilizes a closed-loop water recycling structure, reducing water and chemical consumption by 30%. In addition, it minimizes heat loss to reduce power consumption for tank heating.

Easy To Operate

The user-friendly control panel makes it easy for the employee to operate the machine according to manual.

Options Available

We can offer a variety of options to meet your unique cleaning needs, such as one-person operation, pan return conveyor, stacker, rotary filter, 99% drying, etc.

Explore our baking pan washers

Case Studies

PW-58

The PW-58 consists of a wash zone, a rinse zone, a disinfection zone, and a blow-off zone, which can clean 600 pans per hour and blow off 80% of the water on its surface.

As an entry-level model, this compact washer can meet your basic sheet pan cleaning needs.

Model: PW-58
Size: 5800*1800*1750 mm
Capacity: Washes 600 pans per hour
Drying effect: Approximately 80%
Control method: Button Control
Required operators: 2

PW-95

PW-95 is an automated cleaning system that only requires one worker to operate, effectively reducing labor costs. It adds a hot air drying area, a conveyor system, and two collection bins based on the PW-58.

This sheet pan washer can clean 450 pans per hour, and the drying effect can reach 99%, so the dried pans can be stacked directly without additional wiping. In addition, this machine can also clean 5-gallon buckets, so you only need one machine to clean both types of containers, saving budget and floor space costs.

Model: PW-95
Size: 9500*3000*1850 mm
Capacity: Washes 450 pans per hour
Drying effect: Approximately 99%
Control method: Button Control
Required operators: 1

How It Works

01

Pre-wash

Use high-flow water to rinse away large-sized contaminants and soften stubborn stains such as oil and baked-on residue. The water temperature depends on the type of stain.

02

Main Wash

Deep-clean the pan using powerful high-pressure hot water to remove stubborn stains from the pan’s surface. The cleaned water will be filtered and returned to the water tank for recycling

03

Rinse

Rinse off the detergent or disinfectant residue on the surface of the pan with clean water. Some industries may require rinsing with hot water at 85°C due to strict hygiene requirements.

04

Drying

Use air blowers + air knives to blow most of the water off the pan surface. If you need to put these pans into a new turnover process immediately, we can add a hot air dryer to achieve 99% dryness.

Features

Food-grade 304 stainless steel construction
Tailor-made based on your pans size
Washes up to 600 pans per hour
Independent washing zones
Adjustable conveyor speed
Dual water filter systems
Automatic water refill and water shortage protection
Adjustable guides for different pan types
Globally well-known accessories
Safety interlocks on access doors
Easily accessible emergency stop buttons
Dosing pump for automatic refilling of disinfectant
Complies with your local three-phase voltage

FAQ

Ready to simplify your pan cleaning?

Our team would be happy to provide a customized solution based on your requirements.
